NS-ACL02 SERIES 20W

1Newsunshine LED Corn Light 20W
Newsunshine LED Corn Light 20W
Newsunshine LED Corn Light
Newsunshine LED Corn Light
1Newsunshine LED Corn Light 20W Newsunshine LED Corn Light 20W Newsunshine LED Corn Light Newsunshine LED Corn Light
NS-ACL02 SERIES 20W

New sunshine20W LED light bulb provides 2500 lumen of deluxe daylight,equivalent to 500-watt incandescent,Power saving up to 80% under the same brightness.These corn cob bulbs fit standard medium base (E26) fixtures and an extra bright atmosphere.

  • General illumination
  • Outdoor use in outdoor luminaires only (minimum Ip65)
  • Reduces lumen maintain flux and working life if used
  • in sealed lamp fixtures. ①

Email: order@newsunshine.net

Phone: +1 201 969 5019 (Robert)

Phone: +1 323 616 7060 (Selia)

Product features

  • 360 - degree lighting angle, natural ventilation and heat dissipation No fan design.
  • Adopt the folding process of high heat conductivity and light stamping aluminum material to increase the heat dissipation area and accelerate the heat dissipation.
  • Green products are light and convenient without ultraviolet and infrared radiation.
  • Not suitable for dimmers ,electronic switches and remote controls .
  • Dust and fire-proof, IP64.
  • Widely replace HID/HPS/MH/CFL.
  • Indoor and outdoor illumination: used toGarden lights, underground parking, supermarkets, hang a wall lamp, lamp warehouse,Office lighting, etc

APPLICATIONS

Product datasheet


Technical data
Rated wattage20-23W
Input Voltage100-277V AC
Operating frequency50/60 Hz
Rated power factor <0.90
Power Efficiency<0.87
Humidity>90%
Ambient temperature-40~45℃
Base (standard designation)E26/E27
Replacement conventional lamp powerHPS/HID/MH/CFL Lamp 65W
DimmableNO

Light technical data
Light Source/Count264pcs2835 0.2W LED
Luminous flux.5000±200Lm
Color temperatureWarm White:3000-3500K
NaturalWhite:4000-5000K
Cool White: 5500-6500K
Color rendering index Ra Ra<80
Starting time0 S
LED Emitter Life50000hrs
Lifepan of LED Lamp35000hrs

SPECIFICATIONS

ModelPowerBaseLumensDim.(E26)CTN sizeCTN quantityCTN weight
NS-ACL 10W-02C10WE26/E271300LM2.36x2.36x6.5in 5.99x5.99x16.51cm20.67x20.67x16.34in 52.5x52.5x41.5cm72pcs39.7lbs 18.01kg
NS-ACL 15W-02C20WE26/E271875LM2.36x2.36x6.5in 5.99x5.99x16.51cm20.67x20.67x16.34in 52.5x52.5x41.5cm72pcs39.7lbs 18.01kg
NS-ACL 20W-02C20WE26/E272500LM20.67x20.67x17.91in 52.5x52.5x45.49cm20.67x20.67x17.91in 52.5x52.5x45.49cm72pcs41.9lbs 19.01kg
